Single Responsibility Principle Demystified

Lately, I’ve sensed some confusion in developers around the Single Responsibility Principle (SRP). Its easy to say every object or abstraction should have a single responsibility. But it’s important to understand what do we mean by responsibility.

So when we talk about SRP, what does single responsibility really mean?

Some developers suggest each public method on a object is exposing a responsibility. If we go by this definition of responsibility we’ll end up with every object having exactly one method. Which does not feel right.

Some developers suggest that each object should do exactly one thing. What do they mean by one thing? When I look at a class or a method, how can I tell if its doing one thing or more than one thing? This definition of SRP is even more vague than the original definition.

For example, if we have a class Foo, do you think, adding the toString() method violates SRP? Do you think toString() is the responsibility of the Foo class? Most developers would agree that toString() really belongs on the Foo class and it does not violate SRP. toString() method usually needs access to the internal instance variables and hence this method really belongs on the respective class.

Lets say, we agree that toString() method should belong on the Foo class. Now going by the same argument, can we add toXML() method on the same class? If no, why not? If yes, when will you stop?

Basically this is a slipper slope. Trying to understand SRP by defining Responsibility does not work for me. Instead I look at it from the “Axis of change” or “Single Reason for Change” lens.  If I look at a class Foo with a method bar() on it; if the class Foo and the method bar() change for 2 different reasons then I think it violates SRP. Irrespective of how many methods it has and how many things it does. (It could be violating other design principles).

Going back to our example, I think adding a toString() method does not violate the SRP coz I don’t see any reason why only the toString() method needs to change and the rest of the class remains unchanged. If we add or remove instance variables, its most likely that both the class and the toString() method will change.

Now what about toXML() method? I think the toXML() method does not belong on the object, coz I see 2 reasons for which the toXML() method can change.

  1. When we add/remove any instance variables
  2. When the XML representation/format changes.

However there is a trade-off here. If you don’t put any method on the class, then how do other objects get the data out (other than breaking encapsulation. Even doing so will increase the coupling.)? On the other hand, if you add such methods, then any changes in the format/representation will effect this object as well. Which does not seem right. So how do you design something which does not violate SRP, does not break encapsulation and also adheres to Open Closed Principle?

One way to solve this puzzle is to add a to() method which takes a Formatter object, so we end up with a to(Formatter collector) method. Depending on what format (XML, YAML, etc) one needs to pass the appropriate Formatter type. For example if you want the XML representation of this Class, you pass a XMLFormatter object to the to() method. The class which has the to() method is responsible to adding what ever data it needs to expose and the Formatter object is responsible for the representation and formatting. This way if the XML schema changes, there is only one places to go make the change. If the instance variables change there is only one place to make the change. (Again this is not 100% true, but this solution is a step forward from the first solution as far as SRP goes).

So look for Reasons to Change, as a way to understand SRP.

BTW, In Uncle Bob’s SRP paper (pdf), he defines SRP as:

There should never be more than one reason for a class to change.

Frankly I find this a little too restrictive. I think there can be more than 1 reasons for the class to change. As far as all those reasons affect the whole class (all or most of the methods) the same way, I think we’ve achieved high cohesion and we can be happy for now.

Also its worth highlighting that SRP applies at multiple levels, right on top at a project level all the way down to your individual lines of code.
