Often we need to create short, more expressive URLs. If you are using Nginx as a reverse proxy, one easy way to create short URLs is to define different locations under the respective server directive and then do a permanent rewrite to the actual URL in the Nginx conf file as follows:

http {
    ....
    server {
        listen          80;
        server_name     www.agilefaqs.com agilefaqs.com;
        server_name_in_redirect on;
        port_in_redirect        on;

        location ^~ /training {
            rewrite ^ http://agilefaqs.com/a/long/url/$uri permanent;
        }

        location ^~ /coaching {
            rewrite ^ http://agilecoach.in$uri permanent;
        }

        location = /blog {
            rewrite ^ http://blogs.agilefaqs.com/show?action=posts permanent;
        }

        location / {
            root   /path/to/static/web/pages;
            index   index.html;
        }

        location ~* ^.+\.(gif|jpg|jpeg|png|css|js)$ {
            add_header Cache-Control public;
            expires max;
            root   /path/to/static/content;
        }
    }
}

I’ve been using this feature of Nginx for over 2 years, but never actually fully understood the different prefixes for the location directive.

If you check Nginx’s documentation for the syntax of the location directive, you’ll see:

location [=|~|~*|^~|@] /uri/ { ... }

The URI can be a literal string or a regular expression (regexp).

For regexps, there are two prefixes:

• “~” for case sensitive matching
• “~*” for case insensitive matching

If we have a list of locations using regexps, Nginx checks each location in the order its defined in the configuration file. The first regexp to match the requested url will stop the search. If no regexp matches are found, then it uses the longest matching literal string.

For example, if we have the following locations:

location ~* /.*php$ {
   rewrite ^ http://content.agilefaqs.com$uri permanent;
}

location ~ /.*blogs.* {
    rewrite ^ http://blogs.agilefaqs.com$uri permanent;
}

location /blogsin {
    rewrite ^ http://agilecoach.in/blog$uri permanent;
}

location /blogsinphp {
    root   /path/to/static/web/pages;
    index   index.html;
}

If the requested URL is http://agilefaqs.com/blogs/index.php, Nginx will permanently redirect the request to http://content.agilefaqs.com/blogs/index.php. Even though both regexps (/.*php$ and /.*blogs.*) match the requested URL, the first satisfying regexp (/.*php$) is picked and the search is terminated.

However let’s say the requested URL was http://agilefaqs.com/blogsinphp, Nginx will first consider /blogsin location and then /blogsinphp location. If there were more literal string locations, it would consider them as well. In this case, regexp locations would be skipped since /blogsinphp is the longest matching literal string.

If you want to slightly speed up this process, you should use the “=” prefix. .i.e.

location = /blogsinphp {
    root   /path/to/static/web/pages;
    index   index.html;
}

and move this location right at the top of other locations. By doing so, Nginx will first look at this location, if its an exact literal string match, it would stop right there without looking at any other location directives.

However note that if http://agilefaqs.com/my/blogsinphp is requested, none of the literal strings will match and hence the first regexp (/.*php$) would be picked up instead of the string literal.

And if http://agilefaqs.com/blogsinphp/my is requested, again, none of the literal strings will match and hence the first matching regexp (/.*blogs.*) is selected.

What if you don’t know the exact string literal, but you want to avoid checking all the regexps?

We can achieve this by using the “^~” prefix as follows:

location = /blogsin {
    rewrite ^ http://agilecoach.in/blog$uri permanent;
}

location ^~ /blogsinphp {
    root   /path/to/static/web/pages;
    index   index.html;
}

location ~* /.*php$ {
   rewrite ^ http://content.agilefaqs.com$uri permanent;
}

location ~ /.*blogs.* {
    rewrite ^ http://blogs.agilefaqs.com$uri permanent;
}

Now when we request http://agilefaqs.com/blogsinphp/my, Nginx checks the first location (= /blogsin), /blogsinphp/my is not an exact match. It then looks at (^~ /blogsinphp), its not an exact match, however since we’ve used ^~ prefix, this location is selected by discarding all the remaining regexp locations.

However if http://agilefaqs.com/blogsin is requested, Nginx will permanently redirect the request to http://agilecoach.in/blog/blogsin even without considering any other locations.

To summarize:

1. Search stops if location with “=” prefix has an exact matching literal string.
2. All remaining literal string locations are matched. If the location uses “^~” prefix, then regexp locations are not searched. The longest matching location with “^~” prefix is used.
3. Regexp locations are matched in the order they are defined in the configuration file. Search stops on first matching regexp.
4. If none of the regexp matches, the longest matching literal string location is used.

Even though the order of the literal string locations don’t matter, its generally a good practice to declare the locations in the following order:

1. start with all the “=” prefix,
2. followed by “^~” prefix,
3. then all the literal string locations
4. finally all the regexp locations (since the order matters, place them with the most likely ones first)

BTW adding a break directive inside any of the location directives has not effect.

“Release Early, Release Often” is a proven mantra, but what happens when you push this practice to it’s limits? .i.e. deploying latest code changes to the production servers every time a developer checks-in code?

At Industrial Logic, developers are deploying code dozens of times a day, rapidly responding to their customers and reducing their “code inventory”.

This talk will demonstrate our approach, deployment architecture, tools and culture needed for CD and how at Industrial Logic, we gradually got there.

Process/Mechanics

This will be a 60 mins interactive talk with a demo. Also has a small group activity as an icebreaker.

Key takeaway: When we started about 2 years ago, it felt like it was a huge step to achieve CD. Almost a all or nothing. Over the next 6 months we were able to break down the problem and achieve CD in baby steps. I think that approach we took to CD is a key take away from this session.

Talk Outline

1. Context Setting: Need for Continuous Integration (3 mins)
2. Next steps to CI (2 mins)
3. Intro to Continuous Deployment (5 mins)
4. Demo of CD at Freeset (for Content Delivery on Web) (10 mins) – a quick, live walk thru of how the deployment and servers are set up
5. Benefits of CD (5 mins)
6. Demo of CD for Industrial Logic’s eLearning (15 mins) – a detailed walk thru of our evolution and live demo of the steps that take place during our CD process
7. Zero Downtime deployment (10 mins)
8. CD’s Impact on Team Culture (5 mins)
9. Q&A (5 mins)

Target Audience

• CTO
• Architect
• Tech Lead
• Developers
• Operations

Context

Industrial Logic’s eLearning context? number of changes, developers, customers , etc…?

Industrial Logic’s eLearning has rich multi-media interactive content delivered over the web. Our eLearning modules (called Albums) has pictures & text, videos, quizes, programming exercises (labs) in 5 different programming languages, packing system to validate & produce the labs, plugins for different IDEs on different platforms to record programming sessions, analysis engine to score student’s lab work in different languages, commenting system, reporting system to generate different kind of student reports, etc.

We have 2 kinds of changes, eLearning platform changes (requires updating code or configuration) or content changes (either code or any other multi-media changes.) This is managed by 5 distributed contributors.

On an average we’ve seen about 12 check-ins per day.

Our customers are developers, managers and L&D teams from companies like Google, GE Energy, HP, EMC, Philips, and many other fortune 100 companies. Our customers have very high expectations from our side. We have to demonstrate what we preach.

Learning outcomes

• General Architectural considerations for CD
• Tools and Cultural change required to embrace CD
• How to achieve Zero-downtime deploys (including databases)
• How to slice work (stories) such that something is deployable and usable very early on
• How to build different visibility levels such that new/experimental features are only visible to subset of users
• What Delivery tests do
• You should walk away with some good ideas of how your company can practice CD

Slides from Previous Talks

We have a few Red Hat Enterprise Linux servers, all run ConfigServer and Security (CSF), which is a Stateful Packet Inspection (SPI) firewall, Login/Intrusion Detection and Security application for Linux servers. Amongst various other things, it looks for port scans, multiple login failures and other things that it thinks are ominous, and locks out the originating IP address by rewriting the iptables firewall rules.

For example, if you try to connect to the same server via http, https, ssh and svn within some short window of time, you are quite likely to incur its wrath. Developers at Industrial Logic often lock themselves out by getting blacklisted.

Generally when this happens, we ssh into one of our other server, connect to the server that has blacklisted us, and execute the following command to see what is going on:

$ sudo /usr/sbin/csf -t

As you can see, csf blacklisted my IP for port scanning.

If your IP is the only record, you can flush the whole temporary block list by executing:

$ sudo /usr/sbin/csf -tf
DROP all opt — in !lo out * 117.193.150.62 -> 0.0.0.0/0
csf: 117.193.150.62 temporary block removed
csf: There are no temporary IP allows

Alternatively you can execute the following command to just remove a specific IP:

$ sudo /usr/sbin/csf -tr

The easiest way to find your (external) IP address is to visit http://www.whatsmyip.org/

If you have a static IP, then you can whitelist yourself by:

$ sudo /usr/sbin/csf -a

Currently at Industrial Logic we use Nginx as a reverse proxy to our Tomcat web server cluster.

Today, while running a particular report with large dataset, we started getting timeouts errors. When we looked at the Nginx error.log, we found the following error:

[error] 26649#0: *9155803 upstream timed out (110: Connection timed out)
while reading response header from upstream,
client: xxx.xxx.xxx.xxx, server: elearning.industriallogic.com, request:
"GET our_url HTTP/1.1", upstream: "internal_server_url",
host: "elearning.industriallogic.com", referrer: "requested_url"

After digging around for a while, I discovered that our web server is taking more than 60 secs to respond. Nginx has a directive called proxy_read_timeout which defaults to 60 secs. It determines how long nginx will wait to get the response to a request.

In nginx.conf file, setting proxy_read_timeout to 120 secs solved our problem.

server {
    listen       80;
    server_name  elearning.industriallogic.com;
    server_name_in_redirect off;
    port_in_redirect        off;

    location / {
        proxy_set_header  X-Real-IP  $remote_addr;
        proxy_set_header  X-Real-Host  $host;
        proxy_read_timeout 120;
        ...
    }
    ...
}

Recently an important client of Industrial Logic’s eLearning reported that access to our Agile eLearning website was extremely slow (23+ secs per page load.) This came as a shock; we’ve never seen such poor performance from any part of the world. Besides, a 23+ secs page load basically puts our eLearning in the category of “useless junk”.

From China	From India

Notice that from China its taking 23.34 secs, while from any other country it takes less than 3 secs to load the page. Clearly the problem was when the request originated from China. We suspected network latency issues. So we tried a traceroute.

Sure enough, the traceroute does look suspicious. But then soon we realized the since traceroute and web access (http) uses different protocols, they could use completely different routes to reach the destination. (In fact, China has a law by which access to all public websites should go through the Chinese Firewall [The Great Wall]. VPN can only be used for internal server access.)

Ahh..The Great Wall! Could The Great Wall have something to do with this issue?

To nail the issue, we used a VPN from China to test our site. Great, with the VPN, we were getting 3 secs page load.

After cursing The Great Wall; just as we were exploring options for hosting our server inside The Great Wall, we noticed something strange. Certain pages were loading faster than others consistently. On further investigation, we realized that all pages served from our Windows servers were slower by at least 14 secs compared to pages served by our Linux servers.

Hmmm…somehow the content served by our Windows Server is triggering a check inside the Great Wall.

What keywords could the Great Wall be checking for?

Well, we don’t have any option other than brute forcing the keywords.

Wait a sec….we serve our content via HTTPS, could the Great Wall be looking for keywords inside a HTTPS stream? Hope not!

May be it has to do with some difference in the headers, since most firewalls look at header info to take decisions.

But after thinking a little more, it occurred to me that there cannot be any header difference (except one parameter in the URL and may be something in the Cookie.) That’s because we use Nginx as our reverse proxy. The actual content being served from Windows or Linux servers should be transparent to clients.

Just to be sure that something was not slipping by, we decided to do a small experiment. Have the exact same content served by both Windows and Linux box and see if it made any difference. Interestingly the exact same content served from Windows server is still slow by at least 14 secs.

Let’s look at the server response from the browser again:

Notice the 15 secs for the initial response to the submit request. This happens only when the request is served by the Windows Server.

We had to look deeper into where those 15 secs are coming from. So we decided to take a deeper look, by using some network analysis tool. And look what we found:

A 14+ sec response from our server side. However this happens only when the request is coming from China. Since our application does not have any country specific code, who else could be interfering with this? There are 3 possibilities:

• Firewall settings on the Windows Server: It was easy to rule this out, since we had disabled the firewall for all requests coming from our Reverse Proxy Server.
• Our Datacenter Network Settings: To prevent against DDOS Attacks from Chinese Hackers. A possibility.
• Low level Windows Network Stack: God knows what…

We opened a ticket with our Datacenter. They responded back with their standard response (from a template) saying: “Please check with your client’s ISP.”

Just as I was loosing hope, I explained this problem to Devdas. When he heard 14 secs delay, he immediately told me that it sounds like a standard Reverse DNS Lookup timeout.

I was pretty sure we did not do any reverse DNS lookup. Besides if we did it in our code, both Windows and Linux Servers should have the same delay.

To verify this, we installed Wire Shark on our Windows servers to monitor Reverse DNS Lookup. Sure enough, nothing showed up.

I was loosing hope by the minute. Just out of curiosity, one night, I search our whole code base for any reverse DNS lookup code. Surprise! Surprise!

I found a piece of logging code, which was taking the User IP and trying to find its host name. That has to be the culprit. But then why don’t we see the same delay on Linux server?

On further investigation, I figured that our Windows Server did not have any DNS servers configured for the private Ethernet Interface we were using, while Linux had it.

Eliminated the useless logging code and configured the right DNS servers on our Windows Servers. And guess what, all request from Windows and Linux now are served in less than 2 secs. (better than before, because we eliminated a useless reverse DNS lookup, which was timing out for China.)

This was fun! Great learning experience.

Time and again, I find developers (including myself) over-relying on our automated tests. esp. unit tests which run fast and  reliably.

In the urge to save time today, we want to automate everything (which is good), but then we become blindfolded to this desire. Only later to realize that we’ve spent a lot more time debugging issues that our automated tests did not catch (leave the embarrassment caused because of this aside.)

I’ve come to believe:

A little bit of manual, sanity testing by the developer before checking in code can save hours of debugging and embarrassment.

Again this is contextual and needs personal judgement based on the nature of the change one makes to the code.

In addition to quickly doing some manual, sanity test on your machine before checking, it can be extremely important to do some exploratory testing as well. However, not always we can test things locally. In those cases, we can test them on a staging environment or on a live server. But its important for you to discover the issue much before your users encounter it.

P.S: Recently we faced Error CS0234: The type or namespace name ‘Specialized’ does not exist in the namespace ‘System.Collections’ issue, which prompted me to write this blog post.

Industrial Logic’s eLearning has a feature where students can upload their programming exercise and get automated, personalized feedback. We do various server-side analysis (automated critique) of the student’s code to score them and to give them feedback about how well they performed in their programming exercises. To do this we need to compile their code on our server.

Recently we upgraded our .Net Compiler from version 2.0 to version 3.5. In version 2.0 we had to provide a reference to System.dll file (located in c:\WINDOWS\Microsoft.NET\Framework\v2.0.50727\System.dll) for compiling. In version 3.5, they don’t have System.dll file. It was replaced by System.core.dll (located in c:\Program Files\Reference Assemblies\Microsoft\Framework\v3.5\System.Core.dll)

After making this change, when we ran the compiler using c:\WINDOWS\Microsoft.NET\Framework\v3.5\Csc.exe we got the following error:

Microsoft (R) Visual C# 2008 Compiler version 3.5.30729.1
for Microsoft (R) .NET Framework version 3.5
Copyright (C) Microsoft Corporation. All rights reserved.

SomeCSharpClass.cs: error CS0234: The type or namespace name ‘Specialized’ does not exist in the namespace ‘System.Collections’ (are you missing an assembly reference?)

It turns out that ‘System.collections.specialized’ namespace used to exist in System.dll in .net 2.0. In 3.5 System.Core.dll (which replaced the System.dll) does not contain it. Hence the compile time error.

We’ve fixed this issue by adding both System.Core.dll (v3.5) and System.dll (v2.0) to the compiler reference path. Not sure if this is the right thing to do. But it seems to work.

Branching is a powerful tool in managing development and releases using a version control system. A branch produces a split in the code stream.

One recurring debate over the years is what goes on the trunk (main baseline) and what goes on the branch. How do you decide what work will happen on the trunk, and what will happen on the branch?

Here is my rule:

Branch rarely and branch as late as possible. .i.e. Branch only when its absolutely necessary.

You should branch whenever you cannot pursue and record two development efforts in one branch. The purpose of branching is to isolate development effort. Using a branch is always more involved than using the trunk, so the trunk should be used in majority of the cases, while the branch should be used in rare cases.

According to Ned, historically there were two branch types which solved most development problems:

• Fixes Branch: while feature work continues on the trunk, a fixes branch is created to hold the fixes to the latest shipped version of the software. This allows you to fix problems without having to wait for the latest crop of features to be finished and stabilized.
• Feature Branch: if a particular feature is disruptive enough or speculative enough that you don’t want the entire development team to have to suffer through its early stages, you can create a branch on which to do the work.

Continuous Delivery (and deployment) goes one step further and solves hard development problems and in the process avoiding the need for branching.

What are the problems with branching?

• Effort, Time and Cognitive overhead taken to merge code can be actually significant. The later we merge the worse it gets.
• Potential amount of rework and bugs introduced during the merging process is high
• Cannot dynamically create a CI build for each branch, hence lack of feedback
• Instead of making small, safe and testable changes to the code base, it encourages developers to make big bang, unsafe changes

P.S: I this blog, I’m mostly focusing on Client-Server (centralized) version control system. Distributed VCS (DVCS) have a very different working model.

Over the last 6 months, I’ve been blessed with various pharma hacks on almost all my site.

(http://agilefaqs.com, http://agileindia.org, http://sdtconf.com, http://freesetglobal.com, http://agilecoachcamp.org, to name a few.)

This is one of the most clever hacks I’ve seen. As a normal user, if you visit the site, you won’t see any difference. Except when search engine bots visit the page, the page shows up with a whole bunch of spammy links, either at the top of the page or in the footer. Sample below:

Clearly the hacker is after search engine ranking via backlinks. But in the process suddenly you’ve become a major pharma pimp.

There are many interesting things about this hack:

• 1. It affects all php sites. WordPress tops the list. Others like CMS Made Simple and TikiWiki are also attacked by this hack.
• 2. If you search for pharma keywords on your server (both files and database) you won’t find anything. The spammy content is first encoded with MIME base64 and then deflated using gzdeflate. And at run time the content is eval’ed in PHP.

This is how the hacked PHP code looks like:

If you inflate and decode this code it looks like:

• 3. Well documented and mostly self descriptive code.
• 4. Different PHP frameworks have been hacked using slightly different approach:
  • In WordPress, the hackers created a new file called wp-login.php inside the wp-includes folder containing some spammy code. They then modified the wp-config.php file to include(‘wp-includes/wp-login.php’). Inside the wp-login.php code they further include actually spammy links from a folder inside wp-content/themes/mytheme/images/out/’.$dir’
  • In TikiWiki, the hackers modified the /lib/structures/structlib.php to directly include the spammy code
  • In CMS Made Simple, the hackers created a new file called modules/mod-last_visitor.php to directly include the spammy code.
    Again the interesting part here is, when you do ls -al you see:

    -rwxr-xr-x 1 username groupname 1551 2008-07-10 06:46 mod-last_tracker_items.php

    -rwxr-xr-x 1 username groupname 44357 1969-12-31 16:00 mod-last_visitor.php

    -rwxr-xr-x 1 username groupname 668 2008-03-30 13:06 mod-last_visitors.php

    In case of WordPress the newly created file had the same time stamp as the rest of the files in that folder

How do you find out if your site is hacked?

• 1. After searching for your site in Google, check if the Cached version of your site contains anything unexpected.

• 2. Using User Agent Switcher, a Firefox extension, you can view your site as it appears to Search Engine bot. Again look for anything suspicious.

• 3. Set up Google Alerts on your site to get notification when something you don’t expect to show up on your site, shows up.

• 4. Set up a cron job on your server to run the following commands at the top-level web directory every night and email you the results:
  • mysqldump your_db into a file and run
  • find . | xargs grep “eval(gzinflate(base64_decode(“

If the grep command finds a match, take the encoded content and check what it means using the following site: http://www.tareeinternet.com/scripts/decrypt.php

If it looks suspicious, clean up the file and all its references.

Also there are many other blogs explaining similar, but different attacks:

• Check Your Sites With Google
• WebShell Hack – An Update
• Understanding and cleaning the Pharma hack on WordPress
• WordPress Exploit: We Been Hit By Hidden Spam Link Injection
• Spam Link Injection Hacked (and How I Hopefully Fixed It)
• Google Cloaking Hack Targeting WordPress & How to Fix It
• How to Diagnose and Remove the WordPress Pharma Hack

Hope you don’t have to deal with this mess.
